Polyurethane Nylon Plate Swivel Castor Brake 200mm 600kg Load

£85.45 excl. VAT £102.54

Product code: BZMJ200NPSWB

Klarna
Downloads: PDF Datasheet Request drawings

All pictures shown are for illustration purposes only.
Actual product may vary due to product specification.

Description

Fabricated white zinc ROHS plated swivel castor with a top plate fixing fitted with a red polyurethane nylon centred wheel with plain bearings and total lock brake. Wheel diameter 200mm, tread width 48mm, overall height 240mm, top plate 138mm x 110mm, hole centres 105mm x 80mm/75mm. Load capacity 600kg.

Additional information

Bearing Type

Plain

Castor Type

Swivel with Total Lock Brake

Colour / Shore Hardness

Red Polyurethane on Nylon Rim / 96 Shore A

Diameter (mm)

200

Fixing Option

Plate

Fork Thickness (mm)

6

Height (mm)

241

Hole Centres (mm)

105 x 80/75

Load Capacity (kg)

600

Plate Size (mm)

138 x 110

Swivel Radius (mm)

156

Temperature Resistance

-20 °C TO +70 °C

To Suit Fixing Bolt (mm)

10

Top Plate Thickness (mm)

7

Tread (mm)

48

Wheel Material

Polyurethane on Nylon
